1.Axial impeller and wide caliber are designed for higher water flow.
2.The motor does not require high voltage equipment to start.
3.The balance both between the motor shaft and impeller is calibrated to reduce noise and vibration during operation.
4.The G series pumps cast parts are made of high-quality cast iron or bronze with stainless steel housing.
5.The cast iron parts are coated with Epoxy to resist
Specialized in
1. Aquaculture farm, fish farm, shrimp farm.
2.Collocation with horticulture, or landscape gardening.
3.Drainage of streams, rivers, farm irrigation, fish ponds.
4. Sewer treatment, water conservancy, waterworks industries.
| Model | PH | Power | Discharge | Pole | Standards Head & Flow | Max Head & Flow | ||||||||||
| φ | HP | (kw) | Inch | Frequency | Head | Flow | Frequency | Head | Flow | Frequency | Capacity | Frequency | Capacity | Weight-Kgs | ||
| hertz | (m) | (m3 /min) | hertz | (m) | (m3 /min) | hertz | (m3 /min) | hertz | (m3 /min) | |||||||
| SAG-1054(U) | 1Ø | ½ | 0.4 | 4″ | 2P | 50HZ | 1.5M | 0.8 | 60HZ | 1.5M | 0.9 | 50HZ | 1.1 | 60HZ | 1.2 | 25 |
| SAG-3054(U) | 3Ø | ½ | 0.4 | 4″ | 2P | 50HZ | 1.5M | 0.8 | 60HZ | 1.5M | 0.9 | 50HZ | 1.1 | 60HZ | 1.2 | 25 |
| SAG-114(U) | 1Ø | 7½ | 0.75 | 4″ | 2P | 50HZ | 1.5M | 1.1 | 60HZ | 1.5M | 1.3 | 50HZ | 1.4 | 60HZ | 1.6 | 26 |
| SAG-314(U) | 3Ø | 1 | 0.75 | 4″ | 2P | 50HZ | 1.5M | 1.1 | 60HZ | 1.5M | 1.3 | 50HZ | 1.4 | 60HZ | 1.6 | 26 |
| SAG-356 | 3Ø | 1 | 3.7 | 6″ | 4P | 50HZ | 3 M | 3 | 60HZ | 4 M | 2.5 | 50HZ | 4 | 60HZ | 3.7 | 75 |
| SAG-3758 | 3Ø | 5 | 5.5 | 8″ | 4P | 50HZ | 4 M | 4 | 60HZ | 4 M | 5 | 50HZ | 6 | 60HZ | 6.5 | 100 |
| SAG-31010 | 3Ø | 10 | 7.5 | 10″ | 4P | 50HZ | 4 M | 6 | 60HZ | 4 M | 7 | 50HZ | 8 | 60HZ | 8.5 | 130 |
| SAG-31512U | 3Ø | 15 | 11 | 12″ | 4P | 50HZ | 4.5M | 7 | 60HZ | 4.5M | 7 | 50HZ | 10 | 60HZ | 10 | 225 |
| SAG-32012U | 3Ø | 20 | 15 | 12″ | 4P | 50HZ | – | – | 60HZ | 6 M | 7.5 | 50HZ | – | 60HZ | 10.5 | 240 |
